9.0Rc Rock Crawling Winch
|
List Price: $1,973.32
Your Price: $1,387.49
Item Number: 71550
Manufacturer: Warn
Manufacturer Part No: 71550
|
|
WARN 9.0Rc Rock Crawling Winch
|
Competitive rock crawling means tackling tough climbs and tight turns. That's why rock crawling rigs need a low-profile, lightweight winch like the WARN 9.0Rc that delivers maximum power in a compact, 54-lb. unit.
Like its professional counterpart, the 9.0R, the 9.0Rc is a short-drum, 9,000 lb. capacity winch that features a 4.8 hp Series Wound Motor for fast line speeds. An exclusive, multi-segment Cam Actuated Brake gives positive operator control during winching.
The 9.0Rc comes standard with 50' of 3/8" diameter synthetic rope. Other features include: a chromate undercoating and gloss red paint that provide superior corrosion resistance; a rugged, 360-degree swivel hook and thimble; an aluminum hawse fairlead; extreme duty winch sealing; and a "Ballistic Nylon" Sliding Sleeve that provides extra protection against abrasion and wear.
The 9.0Rc - a winch built for rock crawlers looking for efficiency, reliability and the legendary WARN performance.
|
| 9.0Rc SPECS/PART NUMBER
|
| Part Number: 71550
|
| Rated Line Pull: 9000 lbs. (4080 kgs.) single-line
|
| Motor: Series Wound, 12V 4.8 hp
|
| Remote Control: Remote switch, 12' (3.7m) lead, S2 elements, integrated flashlight
|
| Geartrain: 3-Stage Planetary
|
| Gear Ratio: 216:1
|
| Lubrication: Aeroshell #17
|
| Clutch (freespooling): Sliding Ring Gear
|
| Brake: Automatic Direct Drive Cone
|
| Drum Diameter/Length: 2.75"/4.75" (7.0cm/12cm)
|
| Weight: 54 lbs. (24.8 kgs)
|
| Rope: 50', 3/8" Synthetic Rope
|
| Fairlead: Polished Aluminum Hawse
|
| Recommended Battery: 650 CCA minimum for winching
|
| Battery Leads: 2 gauge, 72" (1.83m)
|
| Finish: Chromate with high-gloss red paint
|
| Nuts/Bolts: PN 39625
|
|
| PERFORMANCE SPECIFICATIONS
|
Line Pull
Lbs.(Kgs.)
|
Line Speed
FT./min(M/min.)
|
Motor
Current
|
Pull by layer
layer/Lbs(Kgs.)
|
| 0
|
42 (12.8)
|
80 amps
|
1/900 (4082)
|
| 2000
|
16 (4.88)
|
200 amps
|
2/7280 (3302)
|
| 4000
|
11.9 (3.63)
|
285 amps
|
3/6670 (3026)
|
| 6000
|
9.79 (2.98)
|
350 amps
|
4/6230 (2826)
|
| 8000
|
8.01 (2.44)
|
435 amps
|
|
| 9000
|
6.4 (1.94)
|
465 amps
|
|
|
|
|
| Above performance specs are based on first layer of drum
|
|
