JR Products 13865 Multi Purpose Switch 20-Amp
UPC: 756815138659 Prop65: WARNING: This product contains chemicals known to the State of California to cause both Cancer and Reproductive Harm.
Item Description
Multi Purpose Switch; 20 Amp At 125 Volt AC/ 10 Amp At 250 Volt AC/ 12 Amp At 125 Volt AC 3/4 Horsepower/ 10 Amp At 277 Volt AC 3/4 Horsepower/ 30 Amp At 12 Volt DC; Double Pole Double Throw; Momentary-On/ Off/ Momentary-On Reversing Switch; Rocker; 0.835 Inch x 1.457 Inch (Cutout); 0.984 Inch x 0.500 Inch (Switch); Non-Lighted; Black
PROP 65 WARNING: This product may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling. For more information, visit www.P65Warnings.ca.gov
Type: Rocker
Current Rating: 20 Amp At 125 Volt AC/ 10 Amp At 250 Volt AC/ 12 Amp At 125 Volt AC/ 10 Amp At 277 Volt AC
Voltage: 125 Volt/ 250 Volt/ 277 Volt
Number Of Switch Positions: 3
Connector Gender: Male
Terminal Type: Blade
Number Of Terminals: 4
Color: Black
- UL/CSA/RoHS/IP66 Approved
- Limited Lifetime Warranty
|
|
