WFCO WF9540AD Power Center 30/50Amp With 40 Amps Output Current
AC Circuits Two- 50A Mains with up to 12 AC Branch Circuits
DC Circuits 17 (3 30A Max & 14 20A Max)
$351.38
UPC: 816227012173 Prop65: Prop 65 WARNING: This product can expose you to chemicals known to the State of California to cause cancer and/or birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Item Description
WF-9540-AD Power Center: 40 AMPS OF OUTPUT CURRENT
As lithium-ion batteries increase in popularity, WFCO knows that our customers want flexibility. The WF-9540-AD Power Center includes the industry exclusive, Patent Pending Auto-Detect technology. This microprocessor-driven technology will recognize lithium-ion and lead-acid battery chemistries and automatically adjust the charging profile to match the battery type.
No more buttons. No more switches. An accurately charged battery gives RV owners peace of mind. Eliminating the risk of over and under-charging the WF-9540-AD Power Center will maximize your battery life with multi-stage charging and current monitoring in both lead-acid and lithium-ion profiles.
Converter Type Power Center
Input Voltage/Hz 105-130 VAC, 60 Hz
Output Power 545W
Charging Modes 3-stage Intelligent Charge (VRLA/AGM)
Intelligent Charging Stages Absorption, Bulk, Storage (VRLA/AGM)
Battery Adaptability AGM, Lead Acid
Voltage Output Lead Acid – 13.2 – 14.4V DC Range, Lithium-Ion – 13.2 – 14.6 VDC, 13.6 – 14.6 VDC
Bulk Charge Voltage (4 Hrs.) 14.4 V
Absorption Charge Voltage 13.6V
Float Mode (Trickle Charge Voltage)
13.2V DC (trickle charge voltage)
Cooling System
2-Fans Zero Clearance
Efficiency (full load) >80%
Overload Protection
Auto recovery on normal load, Current limiting & shutdown
Short Circuit Protection Auto recovery on normal load
Over Temperature Protection Auto recovery on normal load
Reverse Polarity Protection Fuse Protected, Replaceable by fuse of same rating
Protection Features Over Temperature, Overload, Reverse Polarity (fuse), Short Circuit
AC Main Breaker 50 A
AC Circuits (twin breakers) Two- 50A Mains with up to 12 AC Branch Circuits
Built-in Strain Relief Yes
DC Circuits (Quantity) 17 (3 30A Max & 14 20A Max)
Case Color Black
Case Material Plastic
Certifications FCC Class B compliant, UL
Input Current 8A
Input Power 685W
Dimensions 11.96 W x 15.04 H x 10.04 D inch / 304 W x 382 H x 255 D mm
Weight 7.71 lbs.
Warranty Period Two Year Limited Product Warranty
DC Current 40A
|
|
